2001 Stewart & Stevenson M1088 6x6 FMTV 5th Wheel Tractor
Alternate NSN 2320-01-447-3893
3-Man cab, Cab Over Engine
Cab air spring with integral dampers
- Caterpillar 3126 Turbo diesel engine - 290 HP
- Electronically controlled Allison 7-speed automatic transmission
- Full-time 6 x 6 with locking interaxle differential
- Single reduction axles with outboard planetaries
- 2:1 wheel end gear ratio
- 7.8:1 Overall axle gear ratio
- Full air brakes
- Power steering
- Central Tire Inflation System (CTIS)
- 281" L x 96" W x 112" H
- 161" Wheelbase
- Approach Angle - 40 degrees
- Departure Angle 44 degrees
- 5th Wheel Vertical Load - 25,000 lbs.
- Towed Load - 60,710 lbs.
- 58 MPH governed at gross weight
Pricing Includes a “Fully Processed” Truck:
Each truck is carefully inspected by our trained technicians and serviced to ensure dependable performance and immediate operational readiness upon receipt:
- All major components are checked, tested, and confirmed operating as intended, including:
- Engine thoroughly checked, with all fluids, belts, hoses, and filters serviced or replaced as required
- Cooling system checked and fluids replaced as needed
- Alternator and charging system checked and confirmed operational
- Transmission, Transfer Case, Drive and Steer axles
- Seals checked and replaced as needed
- Oil checked, replaced as needed and properly filled
- Transfer Case – Oil checked, replaced as needed and properly filled
- Drive Axles – Oil checked, replaced as needed and properly filled
- Steer Axle – Oil checked, replaced as needed and properly filled
- Clutch adjusted as needed
- Brakes system checked for proper operation:
- Brake Air lines, Brake Chambers, Check Valves checked and replaced as needed
- Brake shoes adjusted
- CV boots replaced as needed
- Wheel seals checked and replaced as needed
- Parking brake system checked, shoes adjusted
- Air compressor and air lines and tanks checked and confirmed operational as intended
- Lighting confirmed operational as intended:
- Headlights
- Tail lights
- Turn signals
- Marker lights
- Body reflectors
- Batteries replaced, load tested and properly secured
- Tires with 70% or more tread life remaining, including a matching mounted spare tire
- Interior:
- Cleaned: pressure washed, glass and gauges cleaned
- Front and door window glass, door and window operators checked for operation and replaced as needed
- Windshield wipers operating and good wiper blades replaced as needed
- Seat covers in good original condition
- Side view mirrors checked and adjusted
- Gauges tested, verified and operational
- Exterior pressure washed
- Engine pressure washed
- Original paint as shown
- Extensively road tested in all speed ranges and various driving conditions
- Supplied with a transferable title unless stated otherwise in description
